In an era of ever-faster machining, multi-task centres and precision finishing, the tool-holding interface can no longer be treated as an afterthought. The PSC Tool Holder Series from Jiaxing XiRay Industrial Technology Co., Ltd. (XiRay) brings together the advanced PSC (“Polygon Shank Conical”) interface standard with XiRay’s manufacturing know-how to enable high-rigidity, high-repeatability performance. According to XiRay’s website, the PSC series is designed for high-speed milling, drilling, reaming and finishing operations.
https://www.xiray-tools.com/psc-tool-holder-series/
Product Overview
XiRay’s PSC series encompasses three primary segments: • PSC one-piece shank holders • PSC holders for turning-mills series • Modular PSC turning holders. Each segment shares the common PSC interface, enabling manufacturers to standardize tooling across static milling, dynamic/driven tooling and turning operations. This is a major advantage in lean, mixed-mode manufacturing environments.
Key Features & Benefits
PSC interface compatibility: The series supports the standardized PSC coupling (ISO 26623) which offers high torsional rigidity, rapid repeatability and strong clamping stability—essential for high-end machining.
Shrink-fit & high-precision clamping: XiRay specifically mentions “PSC Shrink Fit Tool Holders” providing full 360° uniform clamping force, minimal run-out (≤ 3µm at 3×D) and speed capability up to 40,000 rpm (depending on size).
Turn-mill and modular versatility: The “PSC holder for turning-mills series” includes configurations like double-side turning, 45° turning, radial & axial holders—making the PSC platform useful for modern multitask CNC machines.
Application across key sectors: Target markets include automotive, electronics, medical devices and precision parts manufacturing—areas where cycle-time, surface finish, vibration control and tool life are critical.
Why Choose XiRay’s PSC Series?
For manufacturers progressing toward multi-axis machining, high-mix production or tooling rationalization, XiRay’s PSC series presents serious benefits:
Unified interface means reduced tooling inventory and simpler tool-holder management.
High rigidity + minimal run-out lead to improved surface finish, tighter tolerances and longer tool & spindle life.
Faster change-over times and predictable positioning contribute to higher machine utilization and reduced downtime.
Application Tips & Best Practices
To maximize performance: ensure your machine spindle, turret or driven-tool interface meets the PSC specification; use correct shrink-fit heating/clamping procedures as outlined by XiRay; in turn-mill / multitask setups, leverage the modular PSC turning holders to cover both static and driven tools with one interface platform.
